UNO-3073G

• 板载Intel Celeron 847E 1.1 GHz处理器

• 2 x RS-232/422/485接口，带自动数据流控及2 x RS-232 pin head

• 2 x 10/100/1000Base-T 以太网口

• 支持DVI-I, HDMI两组独立双显

• 音频Mic-in, Line-out

• 9 x USB2.0 接口 (1 x 内置USB 用于密码狗或闪存驱动)

• 支持Windows® WES 2009, WES 7/8操作系统

• 双电源冗余输入

• 板载系统诊断LED显示

• 支持网络唤醒功能

• 机壳与电源地隔离

• 前面板2个支持RAID 0/1 的HDD/SSD支架，方便安装拆卸

• ---

  Onboard Intel Celeron 847E 1.1 GHz processor

• 2 x RS-232 / 422/485 interface with automatic data flow control and 2 x RS-232 pin head

• 2 x 10/100 / 1000Base-T Ethernet port

• Support DVI-I, HDMI two independent dual displays

• Audio Mic-in, Line-out

• 9 x USB2.0 ports (1 x built-in USB for dongle or flash drive)

• Supports Windows® WES 2009, WES 7/8 operating systems

• Dual power redundant inputs

• On-board system diagnostic LED display

• Support Wake-on-LAN function

• Enclosure is isolated from power ground

• Front panel with 2 HDD / SSD brackets supporting RAID 0/1 for easy installation and removal
